Pipe Spool Fabrication Drafting, SpoolFab, SpoolCad And Spoolgen Services

At Aptech Technical Services we have a wide range of strengths in CAD drafting, SpoolFab, SpoolCad, Spoolgen, AutoPlant 3D, CadWorx and pipe spool fabrication drawings.

Pipe Spooling Services
Pipe Spooling Services

  • Prepare a pipe spool fabrication drawings.
  • As-built/red line spools.
  • Generate various reports for QA/QC and purchasing.
  • Isometric Bill of Material verify & approval on SpoolTracker.
  • Upload spool reports on SpoolTracker.
  • Variances clean up on SpoolTracker.

CAD Drafting and Detailing Services
CAD Drafting and Detailing Services (2D & 3D Capabilities)
  • Pressure vessels, heat exchangers.
  • Ladders and platforms.
  • As-built/red line drawings.
  • Detailing of sheet metal projects.
  • Miscellaneous structural steel projects.
  • Converting hand sketches drafting to complete CAD.
Estimation Services
Estimation Services
  • Material take-off (MTO)
  • Factor dia. inch count
  • Supports and field material
  • Weights
  • Surface area of paint estimation
Engineering Design Services
Engineering Design Services
  • Engineered site drawings for storage tank permit applications.
  • Pressure vessel calculations in Compress.
Design Services
Design Services
  • Skid packages
Ready to discuss project? Let’s work together

info@aptechts.com

780-468-0950
